NETZSCH API-676 SCREW MULTIPHASE PUMPS
NOTOS® MULTI SCREW PUMPS
Pump Projects proudly supports Netzsch API-676 Screw Multiphase Pumps. Since 1979 NETZSCH has been manufacturing multi screw pumps to serve a wide range of industries and applications. The most advanced technology is utilized to produce these pumps. Reliability, durability and experience are some reasons why you should choose NETZSCH.
Range of applications NOTOS® pumps are designed to convey low to well lubricating fluids, low to high viscosity, shear sensitive or chemically aggressive media. They are typically used in the following industries:
∙ Oil & Gas
∙ Marine
∙ Power Generation
∙ Tank Storage
∙ Process Industries
Capacity and pressure ranges for Netzsch API-676 Screw Multiphase Pumps are for low to high flows and low to high pressures
∙ Flow rate up to 2500 m³/h
∙ Pressure rate up to 100 bar
∙ Viscosities up to 200.000 cSt
∙ Temperature up to 300 ºC
CHARACTERISTICS
∙ Self-priming
∙ Good suction capability
∙ Continuous flow with low pulsation
∙ Flow with minimal turbulences
∙ Gentle product handling
∙ Low maintenance
∙ Low lifecycle cost
∙ Long service life
∙ Quiet operation
∙ Several mechanical seal options
∙ Magnetic drive optional
∙ Extremely low noise and vibrations
∙ Vertical or horizontal installation
APPLICATIONS
Truck Unloading
∙ Pump NOTOS®: 2 NS
∙ Media: Palm oil
∙ Flow rate: 9,2 m³/h
∙ Pressure: 5,0 bar
∙ Temperature: 50 to 60 °C
∙ Viscosity: 20 to 60 cSt
Boiler Feeding
∙ Pump NOTOS®: 3 NS
∙ Media: Fuel oil
∙ Flow rate: 21,2 m³/h
∙ Pressure: 25 bar
∙ Temperature: 60 °C
∙ Viscosity: 622 cSt
Tank Storage
∙ Pump NOTOS®: 4 NS
∙ Media: Oil/Water emulsion
∙ Flow rate: 100 to 127m³/h
∙ Pressure: 18 bar
∙ Temperature: 35 °C
∙ Viscosity: 60 to 250 cSt
